This item, 878855-001, is the HPE spare part number for the product described as 3.84TB SATA 6G Read Intensive SFF 2.5in SC Digitally Signed Firmware SSD. Further details below.
This 960GB SATA SSD is engineered to deliver reliable performance and ample storage capacity for mixed-use server environments. The 2.5-inch SFF form factor allows for easy integration into a wide range of systems, and the 6Gb/s SATA interface ensures fast Data Transfer Rates, with external speeds up to 600 MBps. The drive also comes bundled with an HPE SmartDrive carrier for simplified hot-swap capabilities.
Featuring digitally signed firmware, this item provides enhanced data security and protects against unauthorized access. This SSD is well-suited for applications such as virtualization, database management, and general-purpose server storage. Compatible models includes but may not be limited to BL460c Gen10, DL380 Gen10, DL360 Gen10, ML350 Gen10, DL160 Gen10, DL180 Gen10, DL560 Gen10, DL385 Gen10 Plus, DL580 Gen10, DL325 Gen10 Plus, ML110 Gen10, ML350 Gen11, DL20 Gen10, BL460c Gen9, DL380 Gen9, DL360 Gen9, ML350 Gen9, DL120 Gen9, DL160 Gen9, DL180 Gen9, DL388 Gen9, ML150 Gen9, XL230a Gen9, BL420c Gen8, BL460c Gen8, BL465c Gen8, BL660c Gen8, DL160 Gen8, DL360 Gen8, DL360e Gen8, DL360p Gen8, DL380 Gen8, DL380e Gen8, DL380p Gen8, DL385p Gen8, DL560 Gen8, DL580 Gen8, ML310e Gen8, ML350e Gen8, ML350p Gen8, SL230s Gen8, SL250s Gen8, SL270s Gen8, WS460c Gen8, XL220a Gen8 v2, DL320e Gen8 and DL320e Gen8 v2.
HPE Option Part #: 877764-B21
HPE Spare Part #: 878855-001
PRODUCT SPECIFICATIONS FOR 878855-001:
- Device Type: Solid state drive - hot-swap
- Capacity: 3.84 TB
- NAND Flash Memory Type: Multi-level cell (MLC)
- Form Factor: 2.5" SFF
- Interface: SATA 6Gb/s
- Features: Digitally Signed Firmware, HPE SmartSSD Wear Gauge
- Height: 0.3 in
- Bundled with: HPE Smart Carrier
- Drive Writes Per Day (DWPD): 1
- Drive Class: Read Intensive
- Drive Transfer Rate: 600 MBps (external)
- Internal Data Rate: 500 MBps (read) / 445 MBps (write)
- 4KB Random Read: 59000 IOPS
- 4KB Random Write: 30000 IOPS
- Maximum 4KB Random Write: 30000 IOPS
- Maximum 4KB Random Read: 63000 IOPS
- Average Latency: 60 μs
- Interfaces: 1 x SATA 6 Gb/s
- Compatible Bay: 2.5" SFF
- Power Consumption: 1.35 Watt (idle) | 3 Watt (random read) | 5.44 Watt (random write) | 2.5 Watt (sequential read) | 5.28 Watt (sequential write)
- Compliant Standards: WEEE
COMPATIBLE WITH:
** This list may not be complete. Contact us via Live Chat if you have any questions about compatibility.
HPE PARTSURFER INFO FOR 878855-001 (877764-B21)
| Spare PN | Description |
 | 878855-001 | 3.84TB Solid State Drive (SSD) - SATA interface, 6Gb/s transfer rate, 2.5in small form factor (SFF), read intensive (RI) , digitally signed firmware (SF), smart carrier (SC) |
Last updated: 5/2/2025
