This item, 411064-B21, is the HPE option part number for the product described as Smart Array P400/512MB BBWC Controller. Further details below.
HPE Option Part #: 411064-B21
HPE Spare Part #: 405835-001
HPE Assembly Part #: 012764-003
Specifications:
- Dimensions (not including bracket): Low Profile PCIe Form Factor
- 6.61 in x 2.75 in x 0.7 in (16.8 cm x 7.0 cm x 1.8 cm)
- Disk Drive: 3G SAS (Serial Attached SCSI)
- Enclosure Interface: 1.5G SATA (Serial ATA)
- SAS Connectors: 2 internal (SFF8484) x4 wide port connectors
- Cache Memory Speed: DDR2-533MHz with 40 or 72-bit wide bus provides up to 4.2 GB/s maximum bandwidth.
- Server Interface: x8 2.5G PCIe provides 2GB/s maximum bandwidth.
- SAS Speed: x8 3G SAS provides 2.4GB/s maximum bandwidth.
- Cache Memory: 40-bit 256MB ECC protected cache (72-bit 512MB module upgrades available)
- Logical Drives Supported: Up to 32 logical drives
- Maximum Logical Drive Capacity: 2TB
- Host Memory Addressing: 64-bit, supporting greater than 4GB server memory space
- RAID Support: RAID 6 with ADG (Advanced Data Guarding) requires Battery Backed Write Cache Upgrade
- RAID 5 (Distributed Data Guarding)
- RAID 1+0 (Striping & Mirroring)
- RAID 0 (Striping)
- Upgradeable Firmware: Upgradeable Firmware with recovery ROM feature
- Weight: 2.4 lb
- Dimensions (W x D x H): 7.63 x 11 x 1.25 in
✅ DL160 G5
✅ DL165 G5
✅ DL165 G5p
✅ DL180 G5
✅ DL185 G5
✅ DL320 G4
✅ DL320 G5
✅ DL320 G5p
✅ DL380 G5
✅ DL385 G2
✅ DL385 G5
✅ DL580 G4
✅ DL580 G5
✅ DL585 G2
✅ DL585 G5
✅ DL785 G5
✅ DL785 G6
✅ ML310 G3
✅ ML310 G4
✅ ML310 G5
✅ ML310 G5p
✅ ML350 G5
✅ ML370 G5
✅ ML570 G4
✅ and possibly others
Contact us via Live Chat if you have any questions about compatibility.
