HPE ProLiant SL230s Gen8 Drives
Drives
NOTE: The components of a storage subsystem (e.g. the drive, the HBA/controller, firmware, and the server backplane) should operate at the same data transfer rate or the system bandwidth will be negotiated down to an acceptable level for all components.
NOTE: The non-hot plug hard drives use a quick release carrier.
SAS Hot Plug with Smart Drive SFF (2.5-inch) Enterprise Drives
12G 15K Drives
12G = 12 Gb/sec Transfer Rate Synchronous (Maximum)
15K = 15,000 rpm Rotational Speed
12G 10K Drives
12G = 12 Gb/sec Transfer Rate Synchronous (Maximum)
10K = 10,000 rpm Rotational Speed
6G 15K Drives
6G = 6 Gb/sec Transfer Rate Synchronous (Maximum)
15K = 15,000 rpm Rotational Speed
6G 10K Drives
6G = 6 Gb/sec Transfer Rate Synchronous (Maximum)
10K = 10,000 rpm Rotational Speed
SAS Hot Plug SmartDrive SFF (2.5-inch) Enterprise 512e Drives
SAS Hot Plug Smart Drive SFF (2.5-inch) Midline Drives
SAS Hot Plug SmartDrive SFF (2.5-inch) Midline 512e Drives
SAS Quick Release SFF (2.5-inch) Enterprise (ENT) Drives
SAS Quick Release LFF (3.5-inch) Enterprise (ENT) Drives
SAS Quick Release LFF (3.5-inch) Midline (MDL) Drives
6G SATA Hot Plug with Smart Drive SFF (2.5-inch) Midline (MDL) Drives
6G SATA Quick Release SFF (2.5-inch) Midline (MDL) Drives
6G SATA Quick Release LFF (3.5-inch) Midline (MDL) Drives
6G SAS ME Hot Plug SFF (2.5-inch) Enterprise Mainstream Solid State Drives
$1,133
$776.00
$426
$304.00
6G SAS MLC Hot Plug SFF (2.5-inch) Enterprise Mainstream Solid State Drives
$2,365
$1,598.00
$1,318
$955.00
6G SAS SLC Hot Plug SFF (2.5-inch) Enterprise Performance Solid State Drives
3G SATA MLC Hot Plug SFF (2.5-inch) Enterprise Mainstream Solid State Drives
$444
$302.00
$464
$329.00
3G SATA MLC Quick Release SFF (2.5-inch) Enterprise Mainstream Solid State Drives
$599
$428.00
$621
$438.00
$354
$255.00
NOTE: The hard drive options are not required when configuring a drive-less model.
Drive Cage Kits

NOTE: The Front Hot Plug cage kit, enables two hot plug drives to be implemented in the front bezel. Drives can be implemented individually in order to support a FlexibleLOM or riser card option in the opposite slot.
$170
$122.00

NOTE: The LFF kit enables two (2) 3.5" QR drives.
$95
$70.00

NOTE: The SFF kit enables up to four (4) 2.5" QR drives.
$157
$110.00
